Paneltronics Breaker 30 Amps w/Reverse Polarity Trip Coil - White - Reel Draggin' Tackle

Paneltronics Breaker 30 Amps w/Reverse Polarity Trip Coil - White

  • $4699
  • Save $18


Shore Main Circuit Breakers and Reverse Polarity Trip Coil


  • Amperage: 30 amps
  • Poles: Triple Pole
  • Shore main AC circuit breaker for Paneltronics electrical distribution panels.
    120VAC 60Hz (simultaneously breaks both hot and neutral legs)
    220VAC 50Hz (simultaneously breaks both live and neutral legs)
  • Reverse Polarity Protector 65VAC trip coil (Surge arrestor P/N 281-001 required) (ABYC E-11.6.3.3.1)
  • Smart Breaker: Trips automatically upon sensing reverse polarity.

    Specifications:

    • Box Dimensions: 3"H x 3"W x 3"L WT: 0.4 lbs
    • UPC: 602290204009
