Paneltronics Breaker 25 Amps A-Frame Magnetic Waterproof

Paneltronics Breaker 25 Amps A-Frame Magnetic Waterproof

$26.99 USD
$34.95 USD $26.99 USD
Sale Sold out

Panel Seal / Waterproof "A" Frame Magnetic Circuit Breakers

  • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
  • Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers
  • UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada
  • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
  • Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
    Specifications

    • Handle Color: Metal with Silicon rubber seal
    • Maximum Amperage: 50 Amps
    • Maximum Voltage/AIC: 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC E-11.10.1.5.5)
    • Rated Switch Cycles: Rated Switch Cycles 10,000 actuations at rated current and voltage
    • Electrical Hardware: Screw 10-32 x 3/8" pan combo head (P/N 197-188)
    • Mounting Hardware: Hex nut 1/2-32 (supplied with circuit breaker), Lockwasher 1/2" internal tooth (supplied with circuit breaker)
    • Optional Boot Black silicone rubber (P/N 048-015)

      Specifications:

      • Color: Stainless
      • Throw/Pole: SPST
      • Box Dimensions: 1"H x 2"W x 3"L WT: 0.2 lbs
      • UPC: 602290201442
