Blue Sea 8505 AC Main + Branch A-Series Toggle Circuit Breaker Panel (230V) - Main + 3 Position

Blue Sea 8505 AC Main + Branch A-Series Toggle Circuit Breaker Panel (230V) - Main + 3 Position

Regular price $488.99 USD
Regular price $727.05 USD Sale price $488.99 USD
Sale Sold out

230V AC Main + Branch A-Series Toggle Circuit Breaker Panel

PN: 8505
White Switches


  • (1) 16A Double Pole Circuit Breaker Installed

  • (3) 8A Single Pole Circuit Breakers Installed

  • (1) 8247 AC Digital Multimeter w/ Alarm



  • Features:
    • Red reverse polarity indicating LED
    • All hot, neutral and safety ground buses installed, fully pre-wired
    • All circuit label positions are backlit on standard panels - No kit required
    • "ON" indicating LEDs installed in all circuit positions
    • Maximum panel amperage - 50 Amperes
    • MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance
    • Two-part polyurethane slate gray finish
    • Heavy 1/8" aluminum 5052 alloy
    • Industry standard height and width
    • Countersunk mounting holes throughout
    • Detailed installation instructions and cutout template included
    • Includes set of 30 common Large Format Labels
    • Over 500 individual Labels available


    WarningWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

    Specifications:

    • Voltage: 230v
    • AC/DC: AC
    • Max Breaker Quantity: 3
    • Box Dimensions: 6"H x 10"W x 12"L WT: 3 lbs
    • UPC: 632085085056

    Quick Guide (pdf)
    Owner's Manual (pdf)
